KSNM Drip IRRIGATION Kit - 1/4 acre

₹3,500

~~MRP ₹3,500~~ ₹3,500

Sale Sold out

Inclusive of all Taxes.

Product variants

Quantity

Introduction

The KSNM Drip IRRIGATION Kit - 1/4 acre is a 16 mm drip tape & accessories product listed by KSNM for agricultural use. It is supplied in the specific configuration shown in the product name.

Product Description

DRIP KIT uses Drip Tape. Drip Tape is a thin walled tube. It is normally flat and becomes round when water flows through it. There is no dripper in drip tape. Only simple holes are made with nano technology. Water flows continuously like a jet instead of drop by drop. The major advantage of this technology is that there is NO CLOGGING problem. This is a "Do It Yourself Kit". The kit contains all the parts required for Drip Irrigation for 1/4 Acre Land. DRIP KIT Kit uses DRIP TAPE - 250 PP 45 cm / 9 lph / 16 mm / 1000 meter Match the nominal product specification and the supplier product code (1067) when selecting compatible equipment or replacement components.

Key Features

Wall Thickness: 250 Micron
Diameter: 16 mm
Dripper: No Dripper. Only Simple Laser Punched Holes.
Water Discharge: 9 LPH
Operating Pressure: 1 Kg / cm2
Supplier product page includes additional product-view images

Technical Specifications

Wall Thickness: 250 Micron
Diameter: 16 mm
Dripper: No Dripper. Only Simple Laser Punched Holes.
Water Discharge: 9 LPH
Operating Pressure: 1 Kg / cm2
Area of Coverage: 1000 Sqm (1/4 Acre)
Expected Life: 4 years
Packing Box Size: 27 x 27 x 41 cm
Net Weight: 12 Kg
Gross Weight: 12.5 Kg
Brand / Vendor: KSNM
Supplier product code: 1067

Supplier kit contents / component details (as published):

Sno. | Code | Particulars | Unit | Qty | Rate | INR | USD
1 | 1002 | DRIP TAPE - 250 PP 45 cm / 9 lph / 16 mm / 1000 meter | Meter | 1000 | 2.90 | 2900 | 48.33
2 | 1037 | Grommet / 16 mm | Nos. | 60 | 1.80 | 108 | 1.80
3 | 1040 | Take Off Connector / 16 mm Lock | Nos. | 60 | 2.50 | 150 | 2.50
4 | 1044 | End Cap / 16 mm Lock | Nos. | 60 | 2.00 | 120 | 2.00
5 | 1042 | Straight Connector / 16 mm Lock | Nos. | 20 | 4.00 | 80 | 1.33
6 | 1038 | Drill Bit / Stainless Steel / 16 mm | Nos. | 1 | 150 | 150 | 2.5
TOTAL AMOUNT | 3508 | 58.46
