KSNM Drip Tape - 250 | 16 mm | 9 LPH | 75 cm | 1000 Meter

Introduction

The KSNM Drip Tape - 250 | 16 mm | 9 LPH | 75 cm | 1000 Meter is a 16 mm drip tape & accessories product listed by KSNM for agricultural use. It is supplied in the specific configuration shown in the product name.

Product Description

DRIP TAPE 250 MICRON / 16 mm Size KSNM DRIP TAPE is very simple and affordable by small farmers. KSNM removes the entry barrier for small farmers to adopt drip irrigation technology. Water flows like a jet instead of drop by drop as seen in the photo. There is no dripper in the tube. Instead, simple holes are made to drip tube. Hence clogging problem will never occur. There will be No blockage of holes. Suitable only for above ground installation. Specifications of Drip Tape Water flows like a jet instead of drop by drop as seen in the photo Drip lateral tape is a seamless tube Manufactured from special grade virgin poly ethylene mixture Flexible tape makes it convenient for coiling and recoiling Recommended for closely spaced crops Suitable for above ground laying. Normally the drip tape is flat and becomes round shape when water flows through the tube. Wall thickness – 250 micron ie 10 mil Drip holes are formed in the tape with spacing of 45 cm, 60 cm etc Operating pressure is maximum of 1 kg/cm2 Outer Diameter – 14.6 mm. All 16 mm lateral fittings can be used. Custom order of any thickness, any size and any hole spacing is possible. Match the nominal product specification and the supplier product code (1004) when selecting compatible equipment or replacement components.

Key Features

• Wall Thickness: 250 Micron
• Diameter: 16 mm
• Drip Hole Spacing: 75 cm
• Dripper: No Dripper. Only Simple Holes.
• Water Discharge: 9 LPH
• Supplier product page includes additional product-view images

Technical Specifications

• Wall Thickness: 250 Micron
• Diameter: 16 mm
• Drip Hole Spacing: 75 cm
• Dripper: No Dripper. Only Simple Holes.
• Water Discharge: 9 LPH
• Laying Length: 28 Meter
• Operating Pressure: 1 Kg / cm2
• Expected Life: 4 Years
• Suitable Crop: Closely Spaced Crops, Vegetables etc.
• Net Weight: 10.7 Kg
• Roll Length: 1000 Meter
• Brand / Vendor: KSNM
• Supplier product code: 1004

Applications

• Row-crop drip irrigation
• Controlled water application along beds and crop lines

Country of Origin: India
